LW series mechanical seal,Suitable for SV-AND SVI SERIES LOWARA PUMPS ,12mm-16mm
| Model NO. | EK-LW |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 12 mm to 16 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model LW is suitable for SV-AND SVI SERIES LOWARA PUMPS.The normal material combination is sic/sic/viton/ss304.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤0.5 MPa
Temperature:-20°C~+220°C
Linear Speed:≤20m/s
Materials
Rotary Ring:Carbon
Stationary Ring: SIC
Elastomers: NBR/EPDM/VITON
Springs: SSS304/SS316
Metal Parts: SS304/SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
