Model NO. | EK-156 |
Balance | Unbalanced |
Standard | DIN24960, ISO3069, GB6556 |
Specification | Inner Diameter: 8mm to 16mm |
Packaging Details | Carton |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model 156 is intended for use in industrial and circulating pumps for clean water. Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Pressure: ≤0.5MPa
Temperature: -30C~+200°C
LinearSpeed:≤10m/s
Rotary Ring:Plastic Carbon/Carbon/SIC/TC
Stationary Ring:Ceramic/SIC/TC
Elastomers:NBR/EPDM/VITON
Springs:SS304/SS316
oil, water, weak acid and alkali and other corrosive mediums.
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
