126 series mechanical seal,High temperature and corrosion resistance ,30mm-80mm
126 series mechanical seal,High temperature and corrosion resistance ,30mm-80mm

126 series mechanical seal,High temperature and corrosion resistance ,30mm-80mm

Model NO. EK-126
Balance Unbalanced
Standard DIN24960, ISO3069, GB6556
Specification Inner Diameter 30 mm to 80 mm
Packaging Details Carton
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time 2/day

Views:

We are here to solve your problems in a professional manner

Request Consultation

Our Mechanical seal model 126 has the superior quality of high temperature and corrosion resistance.The normal material combination is sic/sic/VITON/ss304.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.

Operating Limits

Pressure: ≤1.2MPa

Temperature: -20°C~ +150°C

Linear Speed:≤3000r/min

Materials

Rotary Ring:SIC/TC

Stationary Ring:SIC/TC

Elastomers:NBR/EPDM/VITON

Springs:SS304/SS316

Metal Parts: SS304 /SS316

Mediums

water,polluted water,oil and minor corrosive liquid

Customization

Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
